| NVR Technical Specifications | ||
| Model | NVR NVS002 | |
| Video | Video Input | 8 Channel |
| Video Output | 1* HDMI | |
| 1*VGA | ||
| Video Resolution | 1080P/360P | |
| Video Compression | H.265/ H.264/ Smart H.264 | |
| Audio | Audio Input | NO |
| Audio Output | NO | |
| Audio Resolution | NO | |
| Connection | NVR and camera Connection | Wi-Fi , Max 8Channel |
| Network | WiFi | 2.4G |
| Network | Protocol | Private Protocol |
| LAN | Support | |
| WAN | RJ45 Connection, support APP to remotely view 8 channels of monitoring screens at the same time | |
| Hard Disk | Hard Drive | 1x SATA III Port, Up to 4 TB |
| Capacity | Max Up to 4 TB | |
| Record /Playback | Video | Planning video |
| Alarm event recording | ||
| Playback | Instant playback, regular playback, event playback | |
| Video Backup | Support | |
| Alarm | Motion Detection Alarm | Support |
| Video Loss Alarm | Support | |
| Alarm Reminder | Screen prompt, buzzer, APP push | |
| Interface | Network Interface | 1* RJ45 |
| USB Interface | 2*USB2.0 | |
| HDMI Interface | 1*HDMI | |
| VGA Interface | 1* VGA | |
| Power Port | 1*DC 12V 2A (5.5*2.1*10 ) | |
| Type | product Type | IP Camera , Indoor Use |
| Others | Working Temperature | -10 to +50℃ |
| Working Humidity | 10% to 90% RH | |
| Size | Actual Size Final | |
| Weight | About 850g (Actual Weight Final) | |
| Certification | CE, FCC & RoHS | |
| Wireless Camera Specifications | ||
| Camera | Model | NVS002 |
| Camera Quantity | Max 8 pieces Wireless Cameras | |
| System | Main Processor | ARM11 |
| Sensor | 1/2.7”, 2Megapixel progressive scan CMOS | |
| Image Compression | H.265 | |
| Lens | Lens Parameter | Focal length: 3.6mm, 2MP |
| Angle of View | Horizontal:80°, Vertical: 58°, Diagonal: 98° | |
| Video | Resolution | 1080P(1920x1080) / VGA(640x480) |
| Image Frame Rate | 15fps - 25fps | |
| Automatic Exposure | Adjust the image automatically to view clearly | |
| Infrared Mode | Automatic | |
| Night Visibility | Night Vision IR 10 meters | |
| Min.Illuminatioin | 0.01 Lux / F1.2 (With IR Illuminator) | |
| Filter Switch(IR-Cut) | Built-in IR Cut, no color deviation indoor or outdoor | |
| Zoom | App supports 3x digital zoom | |
| Audio | Audio | NO |
| Alarm | Alarm | Motion detection alarm |
| Alarm Notification | Push alarm notifications to your smartphone | |
| Wireless | 2.4G IEEE 802.11 b/g/n, supports WEP, WPA & WPA2 Encryption | |
| Software | SriHome App | iOS &Android |
| Record | Record Mode | Motion detection alarm recording, 7/24 recording |
| Storage | Hard drive ,up to 4TB | |
| Others | Product Type | Mini card camera, waterproof for outdoor or indoor use |
| Ingress Protection | IP66 | |
| Power Supply | DC 5V | |
| Working Temperature | -10 to +50℃ | |
| Working Humidity | 10% to 90% RH | |
| Weight | N.W.:140g (Note:Actual Weight Final) | |
| Accessories | Adaptor, User Manual, Screws | |
| Size | Item size: 84* 84* 100mm (LxWxH) | |
| Packaging size: 115*117*171mm(LxWxH) | ||
| Certification | CE, FCC & RoHS | |
| Warranty | Limited 2-Year Warranty | |
